Manufacturer's direct 2-year warranty self resetting adjustable voltage and current protector
Get the ultimate protection for your electrical systems with our Manufacturer's Direct Self Resetting Adjustable Voltage and Current Protector. This advanced protector offers a 2-Year Warranty, giving you peace of mind and reliability. The Self Resetting feature ensures minimal downtime, while the adjustable voltage and current settings allow you to customize the protection to fit your specific needs. Designed for both residential and commercial use, our protector is the smart choice for safeguarding your valuable equipment. Experience the convenience and security of our factory-backed warranty and enhance your electrical safety today.
- KECN
- WenZhou,China
- 3days
- To be negotiated
- Information
Key attributes
Industry-specific attributes
Phase
Single Phase
Current Type
AC
Other attributes
Place of Origin
Zhejiang, China
Brand Name
KECN
Model Number
AVP-80
Use
Voltage/overvoltage/undervoltage protector
Measuring Range
1~40A 1~63A 1-80A 1-100A
Accuracy Class
Calss 1
Operating Temperature
-25~+50℃
Dimensions
82*35*65mm
Rated Current
40A 63A 80A 100A
Rated voltage
110/120VAC
Warranty period
24 months
Packaging and delivery
Packaging Details
Carton
Port
Shanghai / Ningbo
Supply Ability
Supply Ability
100000 Piece/Pieces per Month
Product Description
Description
1、Circuit will be cut off for overvoltage and undervoltage of the single phase circuit. It will automatic reset the connecting
circuit after the voltage recovery of single-phase circuit and delay of time without manual operation.
2、Circuit protection will produce no malfunction ofr transient of temporary overvoltage, which can avoid voltage instability.
3、Protection device will not be damaged for circuit disconnection of protection device or sudden power recovery after sudden power
failure carused by weak jonits.
4、Protection deveice will not be damaged for the maximum overvoltage of circuit fault
Specification
Rated voltage ：230V
Rated frequency：50/60Hz
Rate current：1A-100A adjustable (default 63A)
Under-voltge action cut-off value: 100V-210V adjustable(defait 170V)
over-voltage action cut-off value: 230V-300V adjustable (default 270V)
Power recovery delay after power failure:5s
Range of time delay: 1s-600s adjustable (default 30s)
Electrical machinery life-span:minimum 50000 times
Exterior dimension:82x35x65mm
Overvoltge and undervoltage restore value is 5V of the set value and overcurrent restore value is 1A less than set value
Rated limit overcurrent：40,63A,80A,100A
1、Circuit will be cut off for overvoltage and undervoltage of the single phase circuit. It will automatic reset the connecting
circuit after the voltage recovery of single-phase circuit and delay of time without manual operation.
2、Circuit protection will produce no malfunction ofr transient of temporary overvoltage, which can avoid voltage instability.
3、Protection device will not be damaged for circuit disconnection of protection device or sudden power recovery after sudden power
failure carused by weak jonits.
4、Protection deveice will not be damaged for the maximum overvoltage of circuit fault
Specification
Rated voltage ：230V
Rated frequency：50/60Hz
Rate current：1A-100A adjustable (default 63A)
Under-voltge action cut-off value: 100V-210V adjustable(defait 170V)
over-voltage action cut-off value: 230V-300V adjustable (default 270V)
Power recovery delay after power failure:5s
Range of time delay: 1s-600s adjustable (default 30s)
Electrical machinery life-span:minimum 50000 times
Exterior dimension:82x35x65mm
Overvoltge and undervoltage restore value is 5V of the set value and overcurrent restore value is 1A less than set value
Rated limit overcurrent：40,63A,80A,100A
High accuracy: AVP digital display overvoltage and undervoltage protectors typically have precise voltage monitoring and display functions, providing real-time voltage readings and allowing users to have a clear understanding of power grid conditions.
Versatility: In addition to overvoltage and undervoltage protection functions, some AVP digital display overvoltage and undervoltage protectors may also have other functions, such as overload protection, short circuit protection, overcurrent protection, etc., providing comprehensive electrical protection.
Easy to install and operate: AVP digital display overvoltage and undervoltage protectors usually have a simple installation and operation process, and users can set and adjust according to instructions.
Our Services & Strength
1. Possess rich industry knowledge and experience, and be able to provide professional solutions and services.
2. Possess a certain competitive advantage in terms of price, providing cost-effective products/services with high-quality/reliable performance. 3. Close cooperation with customers, including understanding and meeting their needs, as well as high-quality after-sales support and services. 4. The company has a good reputation and recognition in the industry. 5. The company has reliability, stability, and sustainability in long-term business operations
FAQ
1.Are there any product features and specifications that I need？ Yes, we are the source manufacturer and can directly consult customer service for 24-hour online service 2.Is the product performance and safety high ？ Our products are made of high-precision materials and undergo random testing before shipment. We also welcome you to visit factories in China or conduct remote factory inspections 3.How about customer service and after-sales service？ Our after-sales warranty period is 24 months. If you have any problems during this period, please feel free to contact us at any time. We also provide customers with ways to obtain technical support, such as online customer service, telephone support, etc 4.Regarding orders and logistics？ We support all shipping methods and suggest sending the address, order quantity, and order details to customer service 5.What is the production capacity of your factory? Our factory has an annual total production capacity of 5 million products. We have multiple production lines, each with a planned production capacity of 300 products per hour. The factory implements efficient production plans and resource allocation to im
