E5EN panel installation PID temperature controller
>

E5EN panel installation PID temperature controller

E5EN panel installation PID temperature controller

Take control of your industrial processes with the E5EN Panel Installation PID Temperature Controller. Designed for seamless integration into your control panels, this Digital PID Thermostat offers precise and reliable temperature management. The E5EN model is an Industrial Process Controller that ensures your systems operate within the desired parameters, enhancing efficiency and productivity. With its user-friendly interface and Panel Installation feature, this Control Panel Thermostat is the smart choice for upgrading your temperature control capabilities. Experience the precision and convenience of the E5EN—elevate your process control to the next level.

Brand: KECN
Product origin: WenZhou,China
Delivery time: 3days
Supply capacity: To be negotiated

Information

Key attributes

Other attributes

Place of Origin

Zhejiang, China

Customized support

OEM

Brand Name

KECN

Model Number

E5EM

Type

E5EN (pointer type) E5EM (digital display type)

Product Selection

Digital temperature controller/pointer temperature controller

panel

L96*W48*H110mm

Hole size

L92*W45mm

Output

Relay (default), SSR (customization required)

Input Type

K type thermocouple

Working power supply

220VAC universal consumption less than or equal to 3W

supply voltage

220V

Packaging and delivery

Packaging Details

Standard export packing or packing as your requirements

Port

NINGBO/SHANGHAI/GUANGZHOU/FUZHOU

Supply Ability

50000 Piece/Pieces per Month

Our E5 series meter totally adopts imported elements with small volume, light weight,beautiful outline, good reliability, strong shock resistance and anti-jamming. It can be widely used for temperature measure and autocontrol in different industries like plastic machinery,rubber machinery,packing machinery,dress, food and printing &dyeing etc.

Tmp. Range	0-99.9°C, 0-199°C, 0-299°C, 0-399°C, 0-999°C
Input Specification	(K,J),PT100Ω
Setting precision	Less than ±1% full scale or range display	Less than 0.5% full scale or range displ
Indicating precision	Less than ±2°C
Control Action	ON/OFF type , proportion type (PD)
Output Mode	Relay connection point 5A 250VAC, voltage of non ecting point 12VDC for SSR use
Rated Voltage	AC:110V/220V/380V±10%,50/60Hz
Proportion Cycle	Relay:15secs, Non connection point :2secs
power Consumption	3W
Ambient Temperature	-10°C~+55°C

Introducing the E5EN PID Controller, a Panel Installation PID Controller designed for seamless integration into your control systems. This Industrial Process Controller is engineered to provide precise temperature regulation, ensuring optimal performance in a variety of applications.

The E5EN PID Controller is not just a device; it's a Digital PID Thermostat that offers advanced control capabilities. With its intuitive interface, you can easily configure and monitor your processes, making it an ideal Control Panel Thermostat for both industrial and commercial settings.

Our Panel Installation PID Controller is built to last, with a robust construction that can withstand the demands of your environment. The E5EN PID Controller's reliability and accuracy make it a trusted choice for maintaining temperature stability in your operations.

The E5EN PID Controller's Digital PID Thermostat features allow for precise control over your heating and cooling systems. As a Control Panel Thermostat, it offers a user-friendly solution that simplifies temperature management.

Experience the efficiency and convenience of the E5EN PID Controller. With its Panel Installation design, setting up and maintaining your temperature control systems has never been easier. Choose the E5EN for your Industrial Process Controller needs and enjoy the peace of mind that comes with reliable temperature regulation.

E5EN PID Controller
