Hot Selling Premium Durable Material 3 Phase Voltage Monitoring Relay Phase Sequence Protector

Secure your industrial operations with our Hot Selling Premium Durable Material 3 Phase Voltage Monitoring Relay, the ultimate Phase Sequence Protector. This reliable phase monitoring solution ensures your machinery runs smoothly and safely, preventing damage from incorrect phase sequences. Engineered with premium materials for durability, our relay is designed to withstand the rigors of your work environment. Make the smart investment for your facility's protection—choose our durable and premium voltage monitoring relay for peace of mind and operational continuity.

  • KECN
  • WenZhou,China
  • 3days
  • To be negotiated
  • Information

Key attributes

Industry-specific attributes

Contact Load
High Power


Other attributes

Protect Your Industrial Operations with the Premium 3 Phase Voltage Monitoring Relay

In the fast-paced world of industrial automation, reliable and efficient voltage monitoring is crucial. Introducing our hot-selling 3 Phase Voltage Relay — a premium device that offers unparalleled protection and durability for your industrial operations.

Designed with Premium Voltage Monitoring capabilities, this relay ensures that your equipment is constantly monitored for any voltage fluctuations or irregularities. With its precision sensors and advanced algorithms, it can detect even the slightest changes in voltage, allowing you to take prompt action and prevent potential damage or downtime.

But what really sets our 3 Phase Voltage Relay apart is its Phase Sequence Protector functionality. Phase sequence errors can lead to catastrophic failures and expensive repairs. Our relay constantly monitors the phase sequence of your electrical system and automatically shuts down the power supply if an irregularity is detected. This ensures that your equipment is always protected from potential harm.

Built with Durable Industrial Relay materials, this device is designed to last. It can withstand the harsh conditions and constant vibrations that are common in industrial environments. Whether you're using it in a factory, power plant, or any other industrial setting, you can rest assured that our relay will provide reliable protection for years to come.

Not only is our 3 Phase Voltage Relay a Phase Sequence Monitoring Relay, but it also offers a wide range of additional features and benefits. It can be easily integrated into your existing system and is compatible with a variety of voltage ranges and frequencies. Plus, its user-friendly interface makes it easy to program and configure according to your specific needs.

In conclusion, our hot-selling 3 Phase Voltage Relay with its Premium Voltage MonitoringPhase Sequence Protector, and Durable Industrial Relay design is the perfect solution for protecting your industrial operations from potential voltage and phase sequence issues. Invest in our premium device and enjoy the peace of mind that comes with having a reliable and dependable voltage monitoring system.

Place of Origin
Zhejiang, China


Brand Name
KECN


Model Number
APR-3


Theory
Solid State Relay


Use
solvent printer


Size
50H * 40W * 58D


Type
APR-3


Mouniing /Socket
PF-085A PF083A(E)


Rated voltage
AC(V):220,240,380,415,440, 50/60Hz


Contact rating
10A 250VAC(Resistive load)


Insulation resistance
100MΩ(DC 500V)min


Dielectric strength
1500VAC


Consumed power
2VA


Ambient temperature
-10℃~+55℃


Ambient humidity
48~85%RH


Weight
90g


Packaging and delivery

Packaging Details
Standard export packing or packing as your requirements


Port
NINGBO/SHANGHAI/GUANGZHOU/FUZHOU


Supply Ability

Supply Ability
50000 Piece/Pieces per Month

3 Phase Voltage Relay

Type
APR-3
Dimensions (mm)
50H × 40W × 58D
Mouniing /Socket
PF-085A PF083A(E)
Functions
which can effectively protect the load
With phase sequence protection function
Rated voltage
AC(V):220,240,380,415,440, 50/60Hz
Contact rating
10A 250VAC(Resistive load)
Mechanical Life
5×106times
Electrical Life
105times
Insulation resistance
100MΩ(DC 500V)min
Dielectric strength
1500VAC
Consumed power
2VA
Ambient temperature
-10℃~+55℃
Ambient humidity
48~85%RH
Weight
90g

Phase Sequence Protector

Premium Voltage Monitoring

3 Phase Voltage Relay

Phase Sequence Protector

Premium Voltage Monitoring

3 Phase Voltage Relay

Phase Sequence Protector

Premium Voltage Monitoring

3 Phase Voltage Relay

Phase Sequence Protector

Premium Voltage Monitoring

3 Phase Voltage Relay
