KES4V63 Self-resetting Overvoltage Undervoltage Protector
>

KES4V63 Self-resetting Overvoltage Undervoltage Protector

KES4V63 Self-resetting Overvoltage Undervoltage Protector

Dual display self resetting current protector 63A switch overcurrent overload voltage lightning protection protector

Brand: KECN
Product origin: WenZhou,China
Delivery time: 3days
Supply capacity: To be negotiated

Information
Video

Key attributes

Introducing the KES4V63 Protector, a state-of-the-art Self-resetting Overvoltage Undervoltage Protector designed to safeguard your electrical systems against the damaging effects of voltage fluctuations. This advanced Voltage Protection Device is your reliable solution for maintaining stable and secure power supply across a wide range of applications.

The KES4V63 Protector is equipped with a unique self-resetting mechanism that automatically restores power once the voltage returns to a safe level, minimizing downtime and ensuring continuous operation. As a dependable Self-resetting Overvoltage Undervoltage Protector, it's the perfect choice for both residential and commercial use, offering peace of mind and protecting your valuable electronics.

Our Voltage Protection Device is user-friendly and easy to integrate into your existing electrical setup. The KES4V63 Protector's intelligent design allows it to detect and respond to both overvoltage and undervoltage conditions, making it an all-in-one solution for your electrical safety needs.

Experience the convenience and reliability of the KES4V63 Protector. With its Self-resetting Overvoltage Undervoltage Protector capabilities, you can trust that your electrical systems are in good hands. Invest in our Voltage Protection Device today and enjoy the peace of mind that comes with comprehensive electrical protection.

Industry-specific attributes

Phase

Single Phase

Current Type

AC

Other attributes

Place of Origin

Zhejiang, China

Brand Name

KECN

Model Number

AVP-63

Usage

Protective devices

Under-voltge action cut-off value

210V-140V adjustable(default 170V)

Range of time delay

1s-600s adjustable(defauIt 30s)

Exterior dimension

85x36x66mm

frequency

50HZ

Rate current

1A-40A adjustable(default 40A)

Over-voltage action cut-off value

230V-300V adjustable(default 280V)

Electrical machinery life-span

minimum 50000 times

air tmeperature

not exceed +40℃ or lower then-5℃

Power recovery delay after power failure

5s

Packaging and delivery

Packaging Details

Carton

Port

Shanghai / Ningbo

Supply Ability

100000 Piece/Pieces per Month

Lead time

Quantity (pieces)	1 - 100	> 100
Lead time (days)	3	To be negotiated

Customization

Customized packaging

Min. order: 2000

Graphic customization

Min. order: 5000

Customized logo

Min. order: 2000

Protection function customization

Min. order: 2000

Product Description

Description
1、Circuit will be cut off for overvoltage and undervoltage of the single phase circuit. It will automatic reset the connecting
circuit after the voltage recovery of single-phase circuit and delay of time without manual operation.
2、Circuit protection will produce no malfunction ofr transient of temporary overvoltage, which can avoid voltage instability.
3、Protection device will not be damaged for circuit disconnection of protection device or sudden power recovery after sudden power
failure carused by weak jonits.
4、Protection deveice will not be damaged for the maximum overvoltage of circuit fault
Specification
Rated voltage ：230V
Rated frequency：50/60Hz
Rate current：1A-100A adjustable (default 63A)
Under-voltge action cut-off value: 100V-210V adjustable(defait 170V)
over-voltage action cut-off value: 230V-300V adjustable (default 270V)
Power recovery delay after power failure:5s
Range of time delay: 1s-600s adjustable (default 30s)
Electrical machinery life-span:minimum 50000 times
Exterior dimension:82x35x65mm
Overvoltge and undervoltage restore value is 5V of the set value and overcurrent restore value is 1A less than set value
Rated limit overcurrent：40,63A,80A,100A

Model number	AVP-63/AVP-40
Rated voltage	220VAC 50HZ or 120VAC 50HZ
Rated current	1A-80A adjustable（default 40A or 63A or 80A）
Over-voltage action cut-off value	240V-300V adjustable（default 270V for 220V rated voltage） 140-200V adjustable（default 170V for 120V rated voltage
Under-voltge action cut-off value	140-210V adjustable（default 170V for 120V rated voltage） 70-100V adjustable（default 80V for 120V rated voltage
Overcurrent action cut -off value	63A 1A-63A can be set (default 40A) 40A: 1A-40A can be set (default 40A)
Boot delay time	1s-300s adjustable(defauIt 5s)
Own Power consumption	≤2W
Electrical mechanical life	≥100,000 times
Working environment	Temperature: -5⁰C～+40⁰C Humidity:＜90% Altitude：≤2000 m

KES4V63 Protector

Single display voltage protector

Self-resetting Overvoltage Undervoltage Protecto

KES4V63 Protector

Details Images

Protection performance: The AVP digital display overvoltage/undervoltage protector can detect abnormal voltage in a timely manner and take rapid protection measures to effectively prevent damage to electrical equipment. It can help extend the service life of electrical equipment.

Single display voltage protector

High accuracy: AVP digital display overvoltage and undervoltage protectors typically have precise voltage monitoring and display functions, providing real-time voltage readings and allowing users to have a clear understanding of power grid conditions.

Versatility: In addition to overvoltage and undervoltage protection functions, some AVP digital display overvoltage and undervoltage protectors may also have other functions, such as overload protection, short circuit protection, overcurrent protection, etc., providing comprehensive electrical protection.

Easy to install and operate: AVP digital display overvoltage and undervoltage protectors usually have a simple installation and operation process, and users can set and adjust according to instructions.

Self-resetting Overvoltage Undervoltage Protecto
